APC Replacement Battery Cartridge #106

Exit
- Battery output voltage:
192 V

Batteries and battery life
- Battery type:
Lead-acid battery

- Installation of batteries:
Closed battery cartridge

- Expected battery life (years):
3-5

- Information about replaceable battery packs:
APCRBC140 consists of two battery modules

- RBC™ quantity:
1

Physical parameters
- Maximum height:
122MM, 12.2cm

- Maximum width:
197MM, 19.7cm

- Maximum depth:
597MM, 59.7cm

- Net weight:
34.55KG

- Gross weight:
37.27KG

- Dimensions of the transport package:
226x409x781MM

- Color:
Black

- Devices on the pallet:
20.0

Environmental Parameters
- Operating temperature:
0 - 40 °C

- Operating range of relative humidity:
0 - 95 (Non-condensing) %

- Operating range of altitude above sea level:
0 - 3048meters

- Storage temperature:
-15 - 45 °C

- Storage relative humidity:
0 - 95 (Non-condensing) %

- Altitude above sea level storage:
0 - 15240 meters

Accordance
- Standard warranty: 2 years for repair or replacement. The warranty period begins to be calculated from the date of sale, but no later than 6 months from the date of production.

Type of product or component
Replaceable battery cartridge

Battery Type
Lead-acid battery

Battery packs per chain
10

Battery connectors are empty
0

Included battery modules
0

Installation of the device
Closed battery cartridge

Battery voltage
120 V

Number of RBC
1

Height
2.99 inches (7.6 cm)

Width
7.99 inches (20.3 cm)

Depth
22.99 inches (58.4 cm)

Net
Weight 49.10 lbs (USA) (22.27 kg)

Mounting mode
Not mounted in a rack

Ambient air temperature during operation
32…104 °F (0…40 °C)

Working height
0...10000 feet

Relative humidity
0...95 %

Ambient temperature during storage
5...113 °F (-15...45 °C)

Storage height
0-50,000 ft (0.00–15,240.00 m)

Relative humidity during storage
0...95 %

Category
11309-APC PRODUCTS FOR RESALE

Discount schedule
APK1

GTIN
731304282686

Returnability
No

Country of origin
PH

Overview Presentation High capacity battery pack for use with Easy UPS 3S with internal battery compartments and empty modular battery cabinet for Easy UPS 3S (E3SXR6). Each battery pack consists of four 9 Ah battery modules. Delivery Time Typically ships within 6 weeks Key Features Product Type Battery Module Product Series Compatibility Easy UPS 3M Battery Type Valve Regulated Lead Acid (VRLA) Easy UPS 3M Series Batteries and Runtimes Free Battery Slots 0 Pre-Installed Batteries 0 Unit Mounting Sealed Battery Pack Battery Voltage 120 V Battery Wattage 9 WAh Physical Parameters Height 15.7 cm Width 42.8 cm Depth 76 cm Net Weight 108 kg Mounting Type Non-Rack Mount Environmental Parameters Ambient Operating Temperature 0…40 °C Altitude 0...3281 ft Relative Humidity 0…95 % non-condensing Ambient Storage Temperature -15…40 °C Storage Altitude 0…15240 m Storage Relative Humidity 0…95 % non-condensing Unit Type of Package 1 PCE Number of units in a package 1 Package 1 Height 18,000 cm Package 1 Width 56,000 cm Package 1 Length 82,000 cm Package weight 112,000 kg

Overview Presentation High capacity battery pack for use with Easy UPS 3S with internal battery compartments and empty modular battery cabinet for Easy UPS 3S (E3SXR6). Each battery pack consists of four 9 Ah battery modules. Delivery Time Typically ships within 6 weeks Key Features Product Type Battery Module Product Series Compatibility Easy UPS 3M Battery Type Valve Regulated Lead Acid (VRLA) Easy UPS 3M Series Batteries and Runtimes Free Battery Slots 0 Pre-Installed Batteries 0 Unit Mounting Sealed Battery Pack Battery Voltage 120 V Battery Wattage 9 WAh Physical Parameters Height 15.7 cm Width 42.8 cm Depth 76 cm Net Weight 108 kg Mounting Type Non-Rack Mount Environmental Parameters Ambient Operating Temperature 0…40 °C Altitude 0...3281 ft Relative Humidity 0…95 % non-condensing Ambient Storage Temperature -15…40 °C Storage Altitude 0…15240 m Storage Relative Humidity 0…95 % non-condensing Unit Type of Package 1 PCE Number of units in a package 1 Package 1 Height 18,000 cm Package 1 Width 56,000 cm Package 1 Length 82,000 cm Package weight 112,000 kg

Battery Type
Maintenance-free sealed lead-acid battery with thickened electrolyte : leak protection

Expected battery life (years)
3-5 years old

Number of battery packs per chain
2

RBC™ quantity
1

Battery installation
Self-contained battery rack

Battery output voltage
24

Maximum height
108mm , 10.8cm

Maximum width
132mm , 13.2cm

Maximum depth
150mm , 15.0cm

Net weight, kg
6.01

Gross weight, kg
7.01

Height of the transport package
203mm , 20.3cm

Depth of transport packaging
224mm , 22.4cm

The width of the transport package
is 168mm , 16.8cm

Devices on a pallet
75

Operating temperature
0 - 40 °C

Operating range of relative humidity
0 - 95 %

Operating range of altitude above sea level
0-3000meters

Storage temperature
-15 - 45 °C

Relative humidity of storage
0 - 95 %

Storage altitude above sea level
0-15000meters

Overview Presentation Ultra high density online power protection with scalable runtime supported by Lithium-Ion batteries. Delivery time Usually in stock Key features Runtime with 3000 W load Min.-max.: 300-3000 W 4 min 37 sec Max. Usable capacity 100% Main Input Voltage 230 V AC 1 phase Product type Uninterruptible power supply (UPS) Other Input Voltage 230 V Main Output Voltage 230 V AC 1 phase Other Output Voltage 230 V Nominal power [W] 3000 W Nominal power 3000 VA Input Connection Type BS1363A British IEC 60320 C20 Schuko CEE 7 / EU1-16P Output connection type 3 IEC 320 C13 2 IEC 320 C19 Quantity Unit 1U Cable length 2.4 m Number of cables 1 Battery type Li-Ion Included hardware RJ45 cable USB cable Safety manual Rack-mounting brackets Stabilization feet Screws Smart-UPS Ultra series Additional features Battery type Li-Ion (Lithium-ion) internal included UPS connectivity Serial port USB port Embedded network management card 3 mounting methods Rack/tower convertible with included kit Batteries and battery life Runtime View Runtime Graph Efficiency View Efficiency Graph Typical recharge time 1.5 h Number of RBC™ cartridges 1 Battery voltage 50 V Charger power (W) 448 W Battery life 8...10 g. Battery life 8...10 g. Spare battery APCRBC173-LI Extended runtime capability 1 General product web sub-family High density spare No Physical parameters Color Silver gray Height 43 mm Width 432 mm Depth 560 mm Net weight 15.9 kg Fastening type No preference Mounting style Rack-mounted with mounting kit Tower-mounted with kit Two-post mount 1 USB-compatible Yes Mounting position Horizontal Vertical Input Network frequency 50/60 Hz autosensing Input voltage limits 160...275 V adjustable (for half load) Input Power Factor at Full Load 1 Output Maximum Configurable Power (W) 3000 W Output Frequency 50/60 Hz +/- 3 Hz synchronized with the utility power Crest Factor 3:1 UPS Type On-Line Waveform Type Sine wave Output voltage THD

Battery Type
Maintenance-free sealed lead-acid battery with thickened electrolyte : leak protection

Expected battery life (years)
3-5 years old

RBC™ quantity
1

Battery installation
Closed battery cartridge

Form factor
Outdoor (Tower)

Maximum height
83mm , 8.3cm

Maximum width
216mm , 21.6cm

Maximum depth
343mm , 34.3cm

Net weight, kg 10.0

Gross weight, kg
10.91

The height of the transport package
is 152mm , 15.2cm

The depth of the transport package
is 495mm , 49.5cm

The width of the transport package
is 368mm , 36.8cm

Colour
Black

Devices on a pallet
20

Operating temperature
0 - 45 °C

Operating range of relative humidity
0 - 95 %

Operating range of altitude above sea level
0-3000meters

Storage temperature
-15 - 45 °C

Relative humidity of storage
0 - 95 %

Storage altitude above sea level
0-15000meters

Rated voltage
220/ 230/ 240 Perem. current

Voltage range
180~280 vac. current (full load) ; 120~300 VAC Current (50% load)

Frequency
40~70 Hz

Power factor
≥ 0.99 (full load)

Rated voltage
208(1), 220, 230, 240 Perem. current

Voltage regulation limits
±1%

Frequency
50/60 ± 3 Hz

Total Harmonic Distortion (THDv)

Power factor
0.9

Connection
IEC C13 x4, C19 x1

Overload capacity

The current amplitude coefficient
is 3:1

Operating mode Efficiency
88-90%

Economical efficiency mode
94%

Battery type
VRLA, external battery module (optional)

Rated voltage
72 In the post. current

Battery quantity
6 pcs

Parallel activation
Up to 4 EBC

Charging current
1/2/4/6 A (adjustable)

Display
LCD display with LED indicators

Port
USB, RS-232, mini-card slot (optional slots for SNMP mini-card, MODBUS mini-card and relay I/O mini-card)

Dimensions (W x D x H)
438 x 410 x 86 mm

Net weight
8.4 kg
