APC Replacement Battery Cartridge #25

Main
- Product or component type Replaceable battery cartridge
- Number of cables 1
- Battery type Lead-acid battery
- Provided equipment All necessary connectors
- Battery Disposal Guide
- Reusable packaging
- Installation instructions

Physical parameters:
- Color Black
- Height 17.3 cm
- Width 15.2 cm
- Depth 18.3 cm
- Net weight 11.68 kg
- The mounting method is not mounted in a rack
- USB-compatible No

Environmental parameters:
- Ambient temperature during operation 0...40 °C
- Working height 0...10000 feet
- Relative humidity 0...95 %
- Ambient temperature during storage -15...45 °C
- Storage height 0.00...15240,00 m
- Relative humidity during storage 0...95 %

Guarantee:
For repair or replacement for a period of 1 year

Product Type
Replaceable battery cartridge

Number of cables
1

Battery Type
Lead-acid battery

Free battery compartments
0

Pre-installed batteries
0

Installation of the device
Stand-alone battery

number of RBC™ cartridges
1

Colour
Black

Height
20,8 cm

Width
16.5 cm

Depth
25,9 cm

Net weight
27,18 kg

Installation execution
Non - stable

Ambient operating temperature
0…40 °C

Altitude above sea level
0...10000 ft

Relative humidity
0...95 %

Ambient temperature during storage
-15…45 °C

Storage height
0,00…15240,00 m

The relative humidity of storage
is 0...95 %

Product Type
Replaceable battery cartridge

Number of cables
1

Battery Type
Lead-acid battery

Free battery compartments
0

Pre-installed batteries
0

Battery voltage
12 V

number of RBC™ cartridges
1

Height
11,2 cm

Width
9.9 cm

Depth
7,4 cm

Net weight
1,7 kg

Installation execution
Non - stable

Battery capacity
4,5 Ah

Ambient operating temperature
0…40 °C

Altitude above sea level
0...10000 ft

Relative humidity
0...95 %

Ambient temperature during storage
-15…45 °C

Storage height
0,00…15240,00 m

The relative humidity of storage
is 0...95 %

Batteries and battery life
Battery type Maintenance-free sealed lead-acid battery with thickened electrolyte : leak protection
Expected battery life (years) 3-5 years
RBC™ quantity 1
Battery installation Closed battery case
Physical
Maximum height 105mm , 10.5cm
Maximum width 151mm , 15.1cm
Maximum depth 65mm , 6.5cm
Gross weight 2.95kg
The height of the transport package is 89mm , 8.9cm
The depth of the transport package is 213mm , 21.3cm
The width of the transport package is 175mm , 17.5cm

Color Black
Devices on a pallet 240
Environment
Operating temperature 0 - 40 °C
Operating range of relative humidity 0 - 95 %
The operating range of altitude above sea level is 0-3000 meters
Storage temperature -15 - 45 °C
Storage relative humidity 0 - 95 %
Storage altitude 0-15000meters
Accordance
Standard warranty for repair or replacement for a period of 1 year
Stable Position Offer
RoHS Compliance
REACH Certification REACH: does not contain particularly dangerous substances

Main Input voltage
12 B direct current

Product Type
Replaceable battery cartridge

Battery Type
Lead-acid battery

Supplied equipment
Installation Guide

Free battery compartments
0

Pre-installed batteries
0

number of RBC™ cartridges
1

Colour
Black

Height
7,6 cm

Width
15,2 cm

Depth
20,3 cm

Net weight
5,2 kg

Installation execution
Non - stable

Operating ambient temperature
0...45 °C

Altitude above sea level
0...10000 ft

Relative humidity
0...95% without condensation

Ambient temperature during storage
-5…45 °C

Storage height
0,00…15240,00 m

Relative humidity of storage
0...95% without condensation

Exit
- Battery output voltage:
192 V

Batteries and battery life
- Battery type:
Lead-acid battery

- Installation of batteries:
Closed battery cartridge

- Expected battery life (years):
3-5

- Information about replaceable battery packs:
APCRBC140 consists of two battery modules

- RBC™ quantity:
1

Physical parameters
- Maximum height:
122MM, 12.2cm

- Maximum width:
197MM, 19.7cm

- Maximum depth:
597MM, 59.7cm

- Net weight:
34.55KG

- Gross weight:
37.27KG

- Dimensions of the transport package:
226x409x781MM

- Color:
Black

- Devices on the pallet:
20.0

Environmental Parameters
- Operating temperature:
0 - 40 °C

- Operating range of relative humidity:
0 - 95 (Non-condensing) %

- Operating range of altitude above sea level:
0 - 3048meters

- Storage temperature:
-15 - 45 °C

- Storage relative humidity:
0 - 95 (Non-condensing) %

- Altitude above sea level storage:
0 - 15240 meters

Accordance
- Standard warranty: 2 years for repair or replacement. The warranty period begins to be calculated from the date of sale, but no later than 6 months from the date of production.

Main Features
- Number of Unit - 2U;
- Battery type - Lead-acid battery.

Batteries and battery life:
- Free battery compartments – 0;
- Pre-installed batteries – 0;
- Battery voltage - 96 V;
- Number of RBC™ cartridges - 2;
- Spare battery - APCRBC152.

Physical parameters
- Color – Black;
- Height - 8.5 cm;
- Width - 43.2 cm;
- Depth - 59.4 cm;
- Net weight - 40.6 kg;
- Installation design – Rack.

Environmental parameters:
- Ambient temperature - 0...40 °C;
- Altitude above sea level - 0...10000 ft;
- Relative humidity - 0...95% without condensation;
- Ambient temperature during storage - (-15...45 °C);
- Storage height - 0,00...15240,00 m;
- Relative humidity of storage - 0...95% without condensation.
