Источник бесперебойного питания SVC V-500-L-LCD

Линейно-Интерактивный ИБП SVC V-500-L

Устройство, позволяющее подключенному оборудованию некоторое время работать от встроенных аккумуляторов, при пропадании электрического тока или при выходе его параметров за допустимые нормы. Кроме того, оно способно корректировать параметры (напряжение, частоту) электропитания. Часто применяется для обеспечения бесперебойной работы компьютеров.

Floor-standing design Purpose for data centers Number of phases (input-output) 3-3 General characteristics Nominal power, kVA 40 Input Nominal voltage 220/380, 230/400, 240/415 VAC (3 phases, 4 wires + ground) Voltage range 305–478 VAC (full load); 228–478 VAC (70% load) Total harmonic distortion of current No more than 2% Power factor Over 0.99 Frequency 40–70 Hz Output Voltage 220/380, 230/400, 240/415 VAC Voltage 24 V DC (3 phase, 4 wires + ground) Total Harmonic Distortion Max. 1.5% with linear load, max. 4% with non-linear load Voltage Regulation Range ±1% (static) Frequency 50/60 Hz Overload Capacity Up to 105% on: continuous operation; Over 105 to 110% on: 60 min; Over 110 to 125% on: 10 min; Over 125 to 150% on: 1 minute; Over 150%: 1 second Battery Nominal Voltage ±240 VDC (default, adjustable from ±180 to ±276 VDC); Charging Voltage - ±272 VDC 204V to 312V DC (Adjustable from 204V to 312V) Charging Time 9.5 minutes (UPS at 70% load with internal battery strings.) Charging Current 15A Communication Interfaces Standard Output Dry Contact x 4, Input Dry Contact x 2, Parallel Port x 2, USB Port x 1, RS232 Port x 1, Remote Emergency Power Off Port x 1, Mini-Card Slot x 2 Efficiency AC-AC Conversion Over 96% (Peak Efficiency) ECO Mode 99% Indication LCD 5" Touch Screen Others Parallel Redundancy and Expansion Up to 4 pcs. Operating Conditions Operating Temperature 0–40°C Relative Humidity 0–95% (non-condensing) Noise Level Less than 56 dB Standards Safety and EMC CE, RCM (IEC62040-1, Class C2 according to IEC62040-2); Protection Class - IP20 (standard); IP42 (optional for long-term redundancy)

Main features
- Output power: 375 Watts / 650VA
- Output connectors:
(4) Schuko CEE 7 (Battery Backup)
- Rated output voltage: 230V
- Rated input voltage: 230V
- Input connection type: Schuko CEE 7/7P
- Length of the cord: 1.5 meters

Exit
- Maximum set power (W): 375 Watts / 650VA
- Output frequency (synchronized with the power grid): 50/60 Hz +/- 1 Hz Not synchronized
- Topology: Linear-interactive
- Type of voltage form: Step approximation of a sinusoid
- Switching time: 6 ms typical: 10 ms maximum

Entrance
- Input frequency: 50/60 Hz +/- 5 Hz Auto-detection
- Input voltage range when operating from the mains: 170-280V
- Number of power cables: 1

Batteries and battery life
- Battery Type: Lead-acid battery
- Typical recharge time: 8 hours
- Rated battery voltage: 12 V
- Expected battery life (years): 3-5

Communication and administrative tools
- Control panel: LED display with indicators on line (mains operation) : on battery ( battery operation)
- Sound signal: Signal of switching to battery operation mode : special signal of battery exhaustion: continuous overload signal

Surge protection and noise filtering
- Burst energy rating: 156joules

Physical parameters
- Maximum height: 93MM, 9.25 cm
- Maximum width: 165MM, 16.5 cm
- Maximum depth: 305MM, 30.5 cm
- Net weight: 4.5 KG
- Gross weight: 4.8 KG
- Dimensions of THE TRANSPORT package: 237x143x373MM
- Color: Black

Environmental parameters
- Operating temperature: 0 - 40 °C
- Operating range of relative humidity: 0-90 %
- Operating altitude range above sea level: 0-2032.1 meters
- Storage temperature: -20-50 °C
- Relative humidity of storage: 0-90 %
- Storage height above sea level: 0-15240 meters
- The level of acoustic noise at a distance of 1 m from the surface of the device: 40.0 dB (A)
- Protection class: IP20

Compliance
- Compliance with the requirements: CE, EN/IEC 62040-1, EN/IEC 62040-2

Standard warranty: 2 years for repair or replacement. The warranty period begins to be calculated from the date of sale, but no later than 6 months from the date of production.

Источник бесперебойного питания APC Easy UPS SRV1KI

Высококачественный онлайн-ИБП с двойным преобразованием, предназначенный для обеспечения необходимой защиты электропитания даже в самых нестабильных условиях . ЭКОЛОГИЧНЫЙ режим/Зеленый режим • Режим энергосбережения, в котором диапазон регулирования входного напряжения может быть установлен/изменен с помощью ЖК-дисплея. Упрощенный мониторинг и управление • USB и последовательные порты для управления ИБП с помощью PowerChute Интеллектуальное управление батареей • Увеличивает производительность, срок службы и надежность батареи благодаря интеллектуальной точной зарядке с температурной компенсацией
