Supermicro mainboard server MBD-X12STL-F-O microATX, Dual LAN with 1GbE with Intel I210, Intel C252 controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10, 1 VGA D-Sub Connector port, 2 SuperDOM with built-in power

Processor
Up to 2 Intel® Xeon® processors Scalable 5th generation with up to 28 cores and Intel® Xeon® processors Scalable 4th generation with up to 32 cores per processor

The operating system
Microsoft® Windows Server® with Hyper-V
RedHat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® vSAN/ESXi®
Canonical® Ubuntu® Server LTS

The chipset
Intel® C741 Chipset

Accelerators
2 x 75W SW, LP

Memory
DIMM speed
Up to 5200 MT/s

Memory type
RDIMM

Slots for memory modules
16 DDR5 DIMM slots

Maximum amount of RAM
1.5 TB

Storage
Front compartment
Up to 8 x 3.5-inch SAS/SATA (HDD/SSD) max. 160 TB
Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max. 240 TB
Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max. 122.88 TB
Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max. 121.6 TB
Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) + 8 x 2.5-inch NVMe (HDD/SSD) max. 244.48 TB

Rear compartment
Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max. 30.72 TB

Storage Controllers
Internal controllers
PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i

External controllers
HBA355e

Software RAID
S160

Internal loading
Boot-optimized storage subsystem (BOSS-N1): HWRAID 1.2 x M.2 NVMe SSD
USB

Safety
Cryptographically signed firmware
Data encryption at rest (SED with local or external key management)
Secure download
Safe erasure
Verification of protected components (hardware integrity check)
Silicon Root of Trust
System Lock (requires iDRAC9 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ

Built-in / on

the iDRAC9 iDRAC Direct
iDRAC RESTful API server with Redfish
iDRAC Service Module
Quick Sync 2 Wireless Module

Consoles
CloudIQ for the PowerEdge plug-in
OpenManage Enterprise
OpenManage Enterprise Integration for VMware® vCenter™
OpenManage Integration for Microsoft® System Center
OpenManage Integration with Windows Admin Center
OpenManage Power Manager plugin
OpenManage Service plugin
OpenManage Update Manager plugin

Mobility
OpenManage Mobile

Tools
Dell Repository Manager Dell System Update

iDRAC RESTful API Corporate Directories with Redfish
IPMI
RACADM CLI

OpenManage integrations
BMC Truesight
Microsoft® System Center
OpenManage Integration with ServiceNow
RedHat® Ansible® Modules
Terraform Suppliers
VMware® vCenter™ and vRealize Operations Manager

Power supplies
1800 W Titanium 200-240V AC or 240 V DC, hot-swappable backup
1400 W Titanium 100-240 V AC or 240 V DC, hot-swappable backup
1400 W Platinum 100-240 V AC or 240 V DC, hot-swappable backup
1400 W Titanium 277 V AC or HVDC (HVDC stands for High-Voltage DC, with 336 V DC), hot-swappable backup
1100 W Titanium 100-240 V AC or 240 V DC, hot-swappable backup
1100 W -(48 V — 60 V) DC, hot-swappable backup
800 W Platinum 100-240 V AC or 240 V DC, hot-swappable backup
700W Titanium 200-240 V AC or 240 V DC, hot-swappable backup
600W Platinum 100-240 VAC or 240 V DC, hot-swappable backup

Fans
Standard (STD) fans, high-performance SLVR fans or high-performance GOLD fans
Up to 6 hot-swappable fans

-Up to two 5th Generation Intel Xeon Scalable processor with up to 28 cores and 4th Generation Intel Xeon Scalable processor with up to 32 cores per processor
- 16 DDR5 DIMM slots, supports RDIMM 1.5 TB max, speeds up to 5200 MT/s, supports registered ECC DDR5 DIMMs only
- Up to 12 x 3.5-inch SAS/SATA (HDD/SSD)
- Embedded Management - iDRAC9, Enterprise
- 2 x 1 GbE LOM
