IP-телефон Fanvil V60W

Grandstream DP755 — это мощная базовая станция DECT VoIP, которая сопрягается с 10 DECT-трубками серии Grandstream DP и обеспечивает мобильность пользователей. В помещении радиус ее действия достигает 50 м, а на улице — 400 м для телефонов DP730 и 350 м — для DP722/DP720. Так пользователи могут свободно перемещаться дома или на работе, оставаясь на связи. К этой базовой станции можно подключить до 10 трубок и 20 SIP-аккаунтов. Она оснащена модулем PoE, отличается четким звуком и поддерживает аудиоконференции до трех участников. Все трубки можно подключить к одному SIP‑аккаунту и получать все вызовы независимо от местоположения. DP755 поддерживает несколько способов автоматической настройки и шифрование TLS/SRTP/HTTPS. При сопряжении с трубками Grandstream DP720, DP722 или DP730 эта базовая станция превращается в мощную беспроводную DECT‑систему, которая подойдет для дома и офиса.

Особенности Grandstream DP755

• Аутентификация и шифрование DECT для защиты звонков и аккаунтов
• Аудиоконференции (до трех участников) для удобной организации совместных звонков
• До 20 SIP-аккаунтов; до 20 линий на трубку
• Режим рации
• Качественный и чистый звук; полнодуплексный спикерфон
• Автоматическая настройка с помощью TR-069 и XML‑файлов конфигурации
• Поддержка расширенных функций: перевода, переадресации и ожидания вызова, функции «Не беспокоить», индикатора сообщений, подсказок на нескольких языках, гибкой настройки абонентских групп и многого другого.
• Настройка Zero Config при использовании с IP‑АТС Grandstream серии UCM

Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV,
NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR- 069, SNMP, 802.1x,
TLS, SRTP*, IPv6

Network interfaces
- Two switched 10/100 Mbps Ethernet ports with auto-detection, built
-in PoE support (only in the GRP2602P model)
- Two switched 10/100/1000 Mbps Ethernet ports with auto-detection,
built-in PoE support (only in the GRP2602G model)

Wi-Fi
GRP2602W, dual-band Wi-Fi module 802.11a/b/g/n/ac (2.4GHz and 5 GHz)

Screen
132 x 48 dots (2.41 inches’) backlit graphic LCD display

Function buttons
2 line buttons with two-color LEDs and support for 4 SIP accounts, 4 XML
context-sensitive on-screen buttons, 5 buttons (navigation,
menu). 8 special function buttons for: MESSAGE (with LED
indicator), TRANSLATION, HEADSET, MICROPHONE MUTE, SEND /
REDIAL, SPEAKERPHONE, VOLUME +, VOLUME

Additional ports
RJ9 headset jack (EHS support for Plantronics, Jabra and Sennheiser headsets)

Voice codecs and capabilities
Support G.729A/B, G.711µ/a-law, G.726, G.722(wide-band), G.723,iLBC, OPUS, in- and
out-of-band DTMF(in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC, AGC, AJB

Telephony functions
Hold, Transfer, Forwarding, 5-way Conference, Call Parking
, Call Interception, Shared Line (SCA)/parallel call indication (BLA),
downloadable phonebook (XML, LDAP, up to 2000 entries), call waiting
, call log (up to 800 entries), auto-dial when you pick up the handset, auto-answer, clickto-dial, flexible number plan, hot table system, personalized
ringtones and music on hold, backup server and fault tolerance

HD Audio
Yes, HD quality in the handset and speaker with broadband sound support

Footing
Yes, 1 position (45°) available, wall mounting option (*
wall mounting bracket sold separately)

QoS
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS

Safety
User and administrative level password, authentication based on
MD5 and MD5-sess, configuration file with 256-bit AES encryption, SRTP*, TLS,
802.1x media access control, secure boot

Supported languages
English, German, Italian, French, Spanish, Portuguese,
Russian, Croatian, Chinese, Korean, Japanese, etc. languages

Update/Automatic configuration
Firmware update via FTP/TFTP/HTTP/HTTPS, group configuration using
GDMS (Grandstream Device Management System), TR-069 or XML
configuration file with AES encryption

Power and energy efficiency
Universal power supply
Input 100-240V AC 50-60Hz;
Output +5V post. current, 600mA;PoE: IEEE802.3af Class 1, 3.84W; IEEE802.3az (EEE) (only
for GRP2602P/GRP2602G model)

Temperature and humidity
Operation: from 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% non-condensing

Package contents
Phone model GRP2602, tube with wire, base, universal power
supply (only for model GRP2602/GRP2602W/GRP2602G), network cable, quick
guide

Sizes
Dimensions: 208mm (L) x 180mm (W) x 63.4mm (H) (with tube)
Device weight:670g; Package weight: 880g (GRP2602/GRP2602W/GRP2602G), 830g
(GRP2602P)

Compliance with standards
GRP2602/GRP2602P/GRP2602G
FCC: Part 15 Class B; FCC Part 68 HAC;
CE: EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 62368-1; RCM: AS/NZS CISPR32;
AS/NZS 62368.1; AS/CA S004;
IC: ICES-003; CS-03;

Compliance with standards
GRP2602W
FCC: Part 15 Subpart B, Class B; FCC Part 15 Subpart E,15.407; FCC Part 68;
CE: EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 62368-1; ETSI EN 301 893;
RCM: AS/NZS CISPR32; AS/NZS 62368.1; AS/CA S004;
IC: RSS-Gen; ICES-003; CS-03.

Protocols/standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A-record, SRV, NAPTR), DHCP,
PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP, IPv6, OpenVPN®

Network interfaces
Two switchable 10/100/1000 Mbps ports with integrated PoE/PoE+ module

Graphic display
8.0" (1280×800) Capacitive LCD Touch Screen, 10 touch points, IPS

Camera
Camera with CMOS sensor, protective curtain and tilt adjustment, 2 MP, 1080p, 30 fps

Bluetooth
Yes, built-in Bluetooth 5.0 module

Wi-Fi
Yes, Dual-band (2.4 and 5 GHz) with 802.11 a/b/g/n/ac/ax, 2T2R, Wi-Fi Display and AirPlay
Additional Connectors RJ9 headset jack (supports EHS headsets with Plantronics adapter), 3.5mm
jack for stereo headsets with microphone, USB 3.0 connector, Type-C, HDMI (output), HDMI (input)

Main buttons 2 function keys: VOLUME +/–, 3 special Android touch keys:
HOME, MENU and BACK

Voice codecs and features
Broadband Opus, Broadband G.722, G.711μ/a, G.729A/B, G.726-32, iLBC, In- and
out-of-band DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC, ANS, Noise Shield 2.0

Video codecs and capabilities
of H.264 BP/MP/HP, video resolution up to 1080p, frame rate up to 30 fps, bitrate up to 4 Mbit/s, video
conference for three participants (1080p, 30 fps), BFCP, camera video (up to 1080p, 30 fps) + The demonstrator
screen correction (up to 1080p, 15 fps), flicker prevention technology, autofocus and auto exposure

Telephony functions
Hold, transfer, forwarding (unconditional/no response/busy line),
call parking, call interception, 12-way audio conference (including creator),
single internal number (shared call appearance, SCA)/bridged line function
line appearance, BLA), virtual universal key, downloading contacts (XML, LDAP, up to
2000 items), call recording (locally and to the server), call log (up to 2000 entries),
call waiting, answering machine, XML screen setup, flexible setting of subscriber groups, personalization
of the ringtone and ringtones on hold, switching to a backup server in case of failure

Typical applications
• Local applications: Contacts, call log, file manager,
softkey, Settings, Browser, Clock, voicemail, Calculator, audio recording, GS store, etc.
• Support for third-party Android apps
• API/SDK available for custom application development

Application Deployment
Support for the development, download, and use of Android 11-compatible apps on
a device with provisioning controls

Android
Uses Android 11 OS

HD audio
Yes, two omnidirectional microphones, an HD headset, and a speaker with broadband
audio support.

Rack
Built-in stand with multiple tilt angles

Quality of service
Layer 2 (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS)

Safety
Passwords for users and administrators, random default administrator password
, MD5 and MD5-session authentication, 256-bit configuration file
AES encryption, TLS, SRTP, 802.1x-based media access control
, Kensington Lock Slot, Secure boot with tamper protection

Languages
English, German, Italian, French, Spanish, Portuguese, Russian,
Croatian, Chinese, Korean, Japanese and others

Update/Setup
Firmware update via TFTP/HTTP/HTTPS or via HTTP local download, mass
configuration using an XML configuration file with TR-069 or AES encryption, GDMS

Nutrition and energy efficiency
A universal power adapter is included in the package. Input: 100-240 V AC;
50-60 Hz; Output: DC12V, 1.5A (18W)
Built-in PoE module * 802.3af, Class 3, PoE+ 802.3at, Class 4
* It is necessary to use a power module or PoE+ to power the phone when using
USB devices.

Temperature and humidity
Operation: 0 to 40 °C; storage: -10 to 60 °C
Humidity: 10 to 90%, non-condensing

Package Contents: GXV3480 phone, headset with cable, stand, universal power adapter, network
cable, screen cloth, quick installation guide

Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record,
SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069,
802.1x, TLS, SRTP*, CDP/SNMP/RTCP-XR

Network interfaces
Dual 10/100/1000Mbps network port with integrated PoE

Graphic display
Graphic LCD display 132*48 (2.95’) pixels with backlight

Function Keys
2 line keys with two-color LED, and 2 SIP account, 3
context-dependent programmable touch keys, eight programmable
BLF extension keys, 5 navigation/menu keys, 13 special
keys with MUTE, HEADSET, TRANSFER, CONFERENCE, SEND, REDIAL functions,
SPEAKERPHONE, VOLUME, PHONEBOOK, MESSAGE, HOLD, PAGE/INTERCOM, RECORD, HOME

Voice codecs
Support G.711µ/a, G.722 (Broadband), G.723, G.726-32, G.729 A/B, iLBC, in
-band and out-of-band DTMF (In audio, RFC2833, SIP INFO)VAD, CNG, AEC, PLC,
AJB, AGC

Telephony Functions
Hold, transfer, redirect (unlimited/no-response/busy),
Shared Call Appearance (SCA) / Bridged Line Appearance(BLA), Downloadable
Phonebook (XML, LDAP, up to 1000 items), Call Waiting
, Call History (up to 200 entries), Auto-call, Automatic Response, One
-click Dialing, Flexible Numbering Plan, Hot Desking, Personalized
Music ringtones, Redundancy servers and fault tolerance
Headset connector Headset with RJ9 connector (which allows the use of EHS with headsets
Plantronics)

HD Audio
Yes, HD tube and speaker with broadband audio support

Base stand
Yes, 2 corner positions are available, the possibility of mounting on the wall

Possibility of mounting on the wall
Yes

QoS
QoS layer 2 (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS)

Safety
User and administrator level access control
, MD5 and MD5-sess authentication, 256-bit encrypted
AES configuration file, media access control SRTP*, TLS, HTTPS, 802.1x

Multilingual support
English, German, Italian, French, Spanish, Portuguese,
Russian, Croatian, Simplified and Traditional Chinese, Korean,
Japanese, etc.

Updating/providing services
Updating the program via TFTP/HTTP/HTTPS, mass provision
of services via TR-069 or AES-encrypted XML configuration file, FTP/FTPS

Energy consumption and environmental energy efficiency
Universal power supply connector 100-240VAC 50-60Hz; Output +5VDC,
600mA; PoE: IEEE802.3af Class 2, 3.84W-6.49W; IEEE802.3az (EEE)

Dimensions and weight
Dimensions 209mm(L) x 184.5mm(W) x 76.2mm(H) (With tube), Device weight: 0.8 kg;
Package weight: 1.2 kg

Temperature and Humidity
For operation: from 0°C to 40°C, Storage: from -10°C to 60°C, Humidity: 10％ - 90%
Non - condensing

Contents of the delivery set
Phone GXP1628, handset with cord, base, universal
power supply, power cord, Quick Start Manual, brochure, license
GPL

Accordance
FCC: Part 15 (CFR 47) Class B, CE : EN55022 Class B, EN55024, EN61000-3-2, EN61000-
3-3, EN60950-1, RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS
60950.1

Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV,
NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR- 069, SNMP, 802.1x,
TLS, SRTP*, IPv6

Network interfaces
- Two switched 10/100 Mbps Ethernet ports with auto-detection, built
-in PoE support (only in the GRP2602P model)
- Two switched 10/100/1000 Mbps Ethernet ports with auto-detection,
built-in PoE support (only in the GRP2602G model)

Wi-Fi
GRP2602W, dual-band Wi-Fi module 802.11 a/b/g/n/ac (2.4GHz and 5 GHz)

Screen
132 x 48 dots (2.41 inches’) backlit graphic LCD display

Function buttons
2 line buttons with two-color LEDs and support for 4 SIP accounts, 4 XML
context-sensitive on-screen buttons, 5 buttons (navigation,
menu). 8 special function buttons for: MESSAGE (with LED
indicator), TRANSLATION, HEADSET, MICROPHONE MUTE, SEND /
REDIAL, SPEAKERPHONE, VOLUME +, VOLUME

Additional ports
RJ9 headset jack (EHS support for Plantronics, Jabra and Sennheiser headsets)

Voice codecs and features
Support G.729A/B, G.711µ/a-law, G.726, G.722(wide-band), G.723,iLBC, OPUS, in- and
out-of-band DTMF(in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC, AGC, AJB

Telephony functions
Hold, Transfer, Forwarding, 5-way Conference, Call Parking
, Call Interception, Shared Line (SCA)/parallel call indication (BLA),
downloadable phonebook (XML, LDAP, up to 2000 entries), call waiting
, call log (up to 800 entries), auto-dial when you pick up the handset, auto-answer, clickto-dial, flexible number plan, hot table system, personalized
ringtones and music on hold, backup server and fault tolerance

HD Audio
Yes, HD quality in the handset and speaker with broadband sound support

Footing
Yes, 1 position (45°) available, wall mounting option (*
Wall mounting bracket sold separately)

QoS
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS

Safety
User and administrative level password, authentication based on
MD5 and MD5-sess, configuration file with 256-bit AES encryption, SRTP*, TLS,
802.1x media access control, secure boot

Supported languages
English, German, Italian, French, Spanish, Portuguese,
Russian, Croatian, Chinese, Korean, Japanese, etc. languages

Update/Automatic configuration
Firmware update via FTP/TFTP/HTTP/HTTPS, group configuration using
GDMS (Grandstream Device Management System), TR-069 or XML
configuration file with AES encryption

Power and energy efficiency
Universal power supply
Input 100-240V AC 50-60Hz;
Output +5V post. current, 600mA;PoE: IEEE802.3af Class 1, 3.84W; IEEE802.3az (EEE) (only
for GRP2602P/GRP2602G model)

Temperature and humidity
Operation: from 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% non-condensing

Package contents
Phone model GRP2602, tube with wire, base, universal power
supply (only for model GRP2602/GRP2602W/GRP2602G), network cable, quick
guide

Sizes
Dimensions: 208mm (L) x 180mm (W) x 63.4mm (H) (with tube)
Device weight:670g; Package weight: 880g (GRP2602/GRP2602W/GRP2602G), 830g
(GRP2602P)

Compliance with standards
GRP2602/GRP2602P/GRP2602G
FCC: Part 15 Class B; FCC Part 68 HAC;
CE: EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 62368-1; RCM: AS/NZS CISPR32;
AS/NZS 62368.1; AS/CA S004;
IC: ICES-003; CS-03;

Compliance with standards
GRP2602W
FCC: Part 15 Subpart B, Class B; FCC Part 15 Subpart E,15.407; FCC Part 68;
CE: EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 62368-1; ETSI EN 301 893;
RCM: AS/NZS CISPR32; AS/NZS 62368.1; AS/CA S004;
IC: RSS-Gen; ICES-003; CS-03.

IP‑телефон Fanvil V61G

Fanvil V61G — стильный и удобный настольный IP‑телефон для корпоративной IP‑телефонии. Устройство оснащено ярким цветным 2.4" экраном, поддерживает до 4 SIP‑линий и обеспечивает качественную связь благодаря технологии HD Voice и современным аудиокодекам.

Телефон оснащён двумя гигабитными портами Ethernet, поддерживает питание PoE и обеспечивает удобный пользовательский интерфейс с программируемыми DSS‑клавишами. Fanvil V61G подходит для офисов, колл‑центров и рабочих мест с высокой нагрузкой.

Основные особенности

• Цветной дисплей 2.4" (320 × 240)
• Поддержка 4 SIP‑линий
• HD Voice с кодеками G.722, Opus и другими
• 6‑сторонняя аудиоконференция
• 2 сетевых порта Gigabit Ethernet (10/100/1000 Мбит/с)
• Поддержка PoE (802.3af)
• До 12 программируемых DSS‑клавиш
• Локальная телефонная книга до 1000 контактов
• Поддержка IPv4 и IPv6
• Поддержка удалённой телефонной книги LDAP/XML
• Настольная или настенная установка
• Разъём RJ9 для гарнитуры

Технические характеристики

• Дисплей: 2.4" цветной LCD 320×240
• SIP‑линии: до 4
• Аудио: HD Voice, G.722, Opus, G.711 и др.
• Конференция: до 6 участников
• Сетевые интерфейсы: 2 × Gigabit Ethernet
• DSS‑клавиши: до 12 программируемых
• Питание: PoE (802.3af) или адаптер питания
• Телефонная книга: до 1000 записей
• Поддержка IPv4 / IPv6
• Монтаж: настольная или настенный
• Гарнитура: RJ9

Применение

IP‑телефон Fanvil V61G идеально подходит для корпоративных рабочих мест, колл‑центров, офисов и других бизнес‑сред, где требуется надёжная проводная VoIP‑связь, высокая скорость сети и удобный интерфейс пользователя для многозадачной телефонной работы.

The GRP2610 is a functional carrier—class IP phone with two lines and automatic
parameter settings, which is suitable for mass deployment and easy to manage. The model features
a stylish design and advanced features, including 8 universal virtual keys and a color LCD display
with a removable panel for changing the appearance of the device (adding a logo, etc.). The GRP series
includes carrier-grade security features for deployment in corporate infrastructures,
including secure boot, two firmware images and data storage with encryption. Phones
The GRP2610 is supported by the Grandstream Device Management System (GDMS), a
cloud—based endpoint deployment configuration, initialization, management, and monitoring center
Grandstream. Designed with the needs of office workers in mind, the GRP2610 phones are designed
for rapid deployment in large enterprises, service provider companies, and other organizations
with a high volume of telephone traffic.

Grandstream DP720 — беспроводной DECT IP телефон

Grandstream DP720 — это DECT‑корпусная беспроводная IP‑трубка, предназначенная для мобильной телефонии в корпоративной среде, на складах, в розничных магазинах или дома. Устройство работает в паре с DECT‑базовыми станциями Grandstream (DP750, DP752 или DP755) и обеспечивает высококачественную голосовую связь, поддержку множества линий и SIP‑аккаунтов, а также стандартные функции офисной телефонии.

Основные характеристики

• Тип: беспроводной DECT IP‑телефон (handset) для VoIP
• Совместимость: работает с базовыми станциями серии DP750 / DP752 / DP755
• Поддержка SIP: до 10 линий и SIP‑аккаунтов на трубку (с DP750/DP752), до 20 линий и SIP‑аккаунтов (с DP755)
• Радиус действия: до 350 м на улице, до 50 м в помещении
• Дисплей: 1.8″ цветной TFT LCD (128×160)
• Клавиатура: 23 клавиши, включая 2 soft‑клавиши, навигационные и функциональные клавиши
• Голосовые кодеки: G.722 (HD), G.726 и дополнительные через базу (G.711, G.723.1, G.729A/B, iLBC, OPUS)
• Аудио: HD‑аудио на трубке и громкой связи, AEC, AGC, подавление фонового шума
• 3‑сторонняя конференция, громкая связь и разъём 3.5 мм для гарнитуры
• Память и функции вызовов: журнал вызовов, удержание, перевод, переадресация, ожидание вызова, автоответ и др.
• DECT‑аутентификация и шифрование для защиты связи
• Многоязычный интерфейс

Питание и батарея

• Аккумулятор: 2 × AAA Ni‑MH LSD (800 mAh)
• Время работы: до ~20 часов разговора и до ~250 часов в режиме ожидания
• Питание зарядной базы: 100‑240 V AC, выход 5 VDC/1 A, возможность подзарядки через micro‑USB

Физические данные и окружение

• Размеры трубки: примерно 155 × 50 × 26 мм; вес около 138 г (без батарей)
• Размеры зарядной базы: ~35 × 63.5 × 54 мм; вес ~71 г
• Рабочая температура: −10 °C до 50 °C; влажность: 10 %–90 % без конденсации
• DECT частоты: 1880–1900 MHz (EU), 1920–1930 MHz (US), 1910–1920 MHz (Brazil) и др.

Преимущества

• Свободное перемещение без привязки к рабочему месту — поддержка большого радиуса действия DECT
• Поддержка до 10/20 SIP аккаунтов для гибкой телефонии (в зависимости от базовой станции)
• Кристально чёткий HD‑звук и встроенный спикерфон для удобного общения
• Широкий набор телефонных функций и совместимость с IP‑АТС
• Удобная многоязычная навигация по меню и интерфейсу

Применение

Grandstream DP720 подходит для использования в офисах, складах, торговых залах и других помещениях, где требуется беспроводной IP‑телефон с высокой мобильностью. В паре с совместимой DECT‑базой он становится частью гибкой VoIP‑системы, обеспечивая стабильную связь и удобство эксплуатации.

Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record,
SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069,
802.1x, TLS, SRTP*, CDP/SNMP/RTCP-XR

Network interfaces
Dual 10/100/1000Mbps network port with integrated PoE

Graphic display
Graphic LCD display 132*48 (2.95’) pixels with backlight

Function Keys
2 line keys with two-color LED, and 2 SIP account, 3
context-dependent programmable touch keys, eight programmable
BLF extension keys, 5 navigation/menu keys, 13 special
keys with MUTE, HEADSET, TRANSFER, CONFERENCE, SEND, REDIAL functions,
SPEAKERPHONE, VOLUME, PHONEBOOK, MESSAGE, HOLD, PAGE/INTERCOM, RECORD, HOME

Voice codecs
Support G.711µ/a, G.722 (Broadband), G.723, G.726-32, G.729 A/B, iLBC, in
-band and out-of-band DTMF (In audio, RFC2833, SIP INFO)VAD, CNG, AEC, PLC,
AJB, AGC

Telephony Functions
Hold, transfer, redirect (unlimited/no-response/busy),
Shared Call Appearance (SCA) / Bridged Line Appearance(BLA), Downloadable
Phonebook (XML, LDAP, up to 1000 items), Call Waiting
, Call History (up to 200 entries), Auto-call, Automatic Response, One
-click Dialing, Flexible Numbering Plan, Hot Desking, Personalized
Music ringtones, Redundancy servers and fault tolerance
Headset connector Headset with RJ9 connector (which allows the use of EHS with headsets
Plantronics)

HD Audio
Yes, HD tube and speaker with broadband audio support

Base stand
Yes, 2 corner positions are available, the possibility of mounting on the wall

Possibility of mounting on the wall
Yes

QoS
QoS layer 2 (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS)

Safety
User and administrator level access control
, MD5 and MD5-sess authentication, 256-bit encrypted
AES configuration file, media access control SRTP*, TLS, HTTPS, 802.1x

Multilingual support
English, German, Italian, French, Spanish, Portuguese,
Russian, Croatian, Simplified and Traditional Chinese, Korean,
Japanese, etc.

Updating/providing services
Updating the program via TFTP/HTTP/HTTPS, mass provision
of services via TR-069 or AES-encrypted XML configuration file, FTP/FTPS

Energy consumption and environmental energy efficiency
Universal power supply connector 100-240VAC 50-60Hz; Output +5VDC,
600mA; PoE: IEEE802.3af Class 2, 3.84W-6.49W; IEEE802.3az (EEE)

Dimensions and weight
Dimensions 209mm(L) x 184.5mm(W) x 76.2mm(H) (With tube), Device weight: 0.8 kg;
Package weight: 1.2 kg

Temperature and Humidity
For operation: from 0°C to 40°C, Storage: from -10°C to 60°C, Humidity: 10％ - 90%
Non - condensing

Contents of the delivery set
Phone GXP1628, handset with cord, base, universal
power supply, power cord, Quick Start Manual, brochure, license
GPL

Accordance
FCC: Part 15 (CFR 47) Class B, CE : EN55022 Class B, EN55024, EN61000-3-2, EN61000-
3-3, EN60950-1, RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS
60950.1
